Bulletin WI-511
Model |
Work Space Dimensions(W x D x H) |
Outside Dimensions(W x D x H) |
Max Temp. |
Blower |
Insulation |
Heat Input |
||
CFM |
HP |
KW |
BTU/HR |
|||||
WRC446-275 |
48" x 48" x 72" |
63" x 82" x 83" |
275oC |
2450 |
1½ |
4" |
30 |
250,000 |
WRC446-350 |
48" x 48" x 72" |
65"x 84" x 84" |
350oC |
2450 |
1½ |
5" |
40 |
300,000 |
WRC446-400 |
48" x 48" x 72" |
69" x 86" x 86" |
400oC |
3000 |
2 |
6" |
45 |
350,000 |
WRC566-275 |
60" x 72" x 72" |
75" x 106" x 83" |
275oC |
3300 |
2 |
4" |
40 |
300,000 |
WRC566-350 |
60" x 72" x 72" |
77" x 108" x 84" |
350oC |
3300 |
2 |
5" |
45 |
350,000 |
WRC566-400 |
60" x 72" x 72" |
81" x 110" x 86" |
400oC |
4000 |
3 |
6" |
60 |
400,000 |
WRC586-275 |
60" x 96" x 72" |
77" x 130" x 83" |
275oC |
4200 |
3 |
4" |
45 |
350,000 |
WRC586-350 |
60" x 96" x 72" |
79" x 132" x 84" |
350oC |
4200 |
3 |
5" |
60 |
400,000 |
WRC586-400 |
60" x 96" x 72" |
83" x 134" x 86" |
400oC |
5000 |
5 |
6" |
80 |
600,000 |
WRC666-275 |
72" x 72" x 78" |
89" x 106" x 89" |
275oC |
4200 |
3 |
4" |
45 |
350,000 |
WRC666-350 |
72" x 72" x 78" |
91" x 108" x 90" |
350oC |
4200 |
3 |
5" |
60 |
400,000 |
WRC666-400 |
72" x 72" x 78" |
95" x 110" x 92" |
400oC |
5000 |
5 |
6" |
80 |
600,000 |
WRC686-275 |
72" x 96" x 78" |
93" x 130" x 90" |
275oC |
6000 |
5 |
4" |
60 |
400,000 |
WRC686-350 |
72" x 96" x 78" |
95" x 132" x 91" |
350oC |
6000 |
5 |
5" |
80 |
600,000 |
WRC686-400 |
72" x 96" x 78" |
97" x 142" x 94" |
400oC |
7800 |
5 |
6" |
100 |
700,000 |
WRC6106-275 |
72" x 120" x 78" |
93" x 162" x 91" |
275oC |
7800 |
5 |
4" |
80 |
600,000 |
WRC6106-350 |
72" x 120" x 78" |
95" x 164" x 92" |
350oC |
7800 |
5 |
5" |
100 |
700,000 |
WRC6106-400 |
72" x 120" x 78" |
100" x 166" x 94" |
400oC |
10,000 |
7½ |
6" |
120 |
800,000 |
WRC6126-275 |
72" x 144" x 78" |
96" x 187" x 91" |
275oC |
10,000 |
7½ |
4" |
80 |
600,000 |
WRC6126-350 |
72" x 144" x 78" |
98" x 188" x 92" |
350oC |
10,000 |
7½ |
5" |
100 |
700,000 |
WRC6126-400 |
72" x 144" x 78" |
100" x 190" x 96" |
400oC |
12,500 |
10 |
6" |
120 |
800,000 |
WRC688-275 |
72" x 96" x 96" |
92" x 139" x 108" |
275oC |
7800 |
5 |
4" |
80 |
600,000 |
WRC688-350 |
72" x 96" x 96" |
94" x 140" x 109" |
350oC |
7800 |
5 |
5" |
100 |
700,000 |
WRC787-275 |
84" x 96" x 84" |
104" x 139" x 95" |
275oC |
7800 |
5 |
4" |
80 |
600,000 |
WRC787-350 |
84" x 96" x 84" |
106" x 104" x 96" |
350oC |
7800 |
5 |
5" |
100 |
700,000 |
WRC7107-275 |
84" x 120" x 84" |
108" x 163" x 97" |
275oC |
10,000 |
7½ |
4" |
80 |
600,000 |
WRC7107-350 |
84" x 120" x 84" |
110" x 164" x 98" |
350oC |
10,000 |
7½ |
5" |
100 |
700,000 |
WRC7127-275 |
84" x 144" x 84" |
108" x 187" x 98" |
275oC |
12,500 |
10 |
4" |
100 |
700,000 |
WRC7127-350 |
84" x 144" x 84" |
110" x 188" x 99" |
350oC |
12,500 |
10 |
5" |
140 |
1,200,000 |
WRC8108-275 |
96" x 120" x 96" |
120" x 163" x 109" |
275oC |
12,500 |
10 |
4" |
120 |
800,000 |
WRC8108-350 |
96" x 120" x 96" |
122" x 164" x 110" |
350oC |
12,500 |
10 |
4" |
120 |
800,000 |
WRC8128-275 |
96" x 144" x 96" |
116" x 193" x 112" |
275oC |
17,500 |
15 |
4" |
140 |
1,200,000 |
WRC8128-350 |
96" x 144" x 96" |
118" x 194" x 113" |
350oC |
17,500 |
15 |
5" |
180 |
1,200,000 |
Model |
Work Space Dimensions (W x D x H) |
Outside Dimensions (W x D x H) |
Max Temp. |
Blower |
Insulation |
Heat Input |
||
CFM |
HP |
KW |
BTU/HR |
|||||
WTC446-500 |
48" x 48" x 72" |
64" x 61" x 113" |
500oF |
2450 |
1½ |
4" |
30 |
250,000 |
WTC446-650 |
48" x 48" x 72" |
66" x 62" x 114" |
650oF |
2450 |
1½ |
5" |
40 |
300,000 |
WTC446-750 |
48" x 48" x 72" |
68" x 64" x 116" |
750oF |
3000 |
2 |
6" |
45 |
350,000 |
WTC566-500 |
60" x 72" x 72" |
76" X 85" X 113" |
500oF |
3300 |
2 |
4" |
40 |
300,000 |
WTC566-650 |
60" x 72" x 72" |
76" x 86" x 114" |
650oF |
3300 |
2 |
5" |
45 |
350,000 |
WTC566-750 |
60" x 72" x 72" |
76" X 88" x 113" |
750oF |
4000 |
3 |
6" |
60 |
400,000 |
WTC586-500 |
60" x 96" x 72" |
76" x 109" x 113" |
500oF |
4200 |
3 |
4" |
45 |
350,000 |
WTC586-650 |
60" x 96" x 72" |
78" x 110" x 114" |
650oF |
4200 |
3 |
5" |
60 |
400,000 |
WTC586-750 |
60" x 96" x 72" |
80" x 112" x 116" |
750oF |
5000 |
5 |
6" |
80 |
600,000 |
WTC666-500 |
72" x 72" x 78" |
88" x 85" x 119" |
500oF |
4200 |
3 |
4" |
45 |
350,000 |
WTC666-650 |
72" x 72" x 78" |
90" x 86" x 120" |
650oF |
4200 |
3 |
5" |
60 |
400,000 |
WTC666-750 |
72" x 72" x 78" |
92" x 88" x 123" |
750oF |
5000 |
5 |
6" |
80 |
600,000 |
WTC686-500 |
72" x 96" x 78" |
88" x 109" x 119" |
500oF |
6000 |
5 |
4" |
60 |
400,000 |
WTC686-650 |
72" x 96" x 78" |
90" x 110" x 120" |
650oF |
6000 |
5 |
5" |
80 |
600,000 |
WTC686-750 |
72" x 96" x 78" |
92" x 112" x 131" |
750oF |
7800 |
5 |
6" |
100 |
700,000 |
WTC6106-500 |
72" x 120" x 78" |
88" x 133" x 128" |
500oF |
7800 |
5 |
4" |
80 |
600,000 |
WTC6106-650 |
72" x 120" x 78" |
88" x 134" x 129" |
650oF |
7800 |
5 |
5" |
100 |
700,000 |
WTC6106-750 |
72" x 120" x 78" |
94" x 136" x 132" |
750oF |
10,000 |
7½ |
6" |
120 |
800,000 |
WTC6126-500 |
72" x 144" x 78" |
90" x 157" x 129" |
500oF |
10,000 |
7½ |
4" |
80 |
600,000 |
WTC6126-650 |
72" x 144" x 78" |
92" x 158" x 130" |
650oF |
10,000 |
7½ |
5" |
100 |
700,000 |
WTC6126-750 |
72" x 144" x 78" |
96" x 160" x 133" |
750oF |
12,500 |
10 |
6" |
120 |
800,000 |
WTC688-500 |
72" x 96" x 96" |
88" x 109" x 146" |
500oF |
7800 |
5 |
4" |
80 |
600,000 |
WTC688-650 |
72" x 96" x 96" |
90" x 110" x 147" |
650oF |
7800 |
5 |
5" |
100 |
700,000 |
WTC787-500 |
84" x 96" x 84" |
100" x 109" x 134" |
500oF |
7800 |
5 |
4" |
80 |
600,000 |
WTC787-650 |
84" x 96" x 84" |
102" x 110" x 135" |
650oF |
7800 |
5 |
5" |
100 |
700,000 |
WTC7107-500 |
84" x 120" x 84" |
102" x 133" x 134" |
500oF |
10,000 |
7½ |
4" |
80 |
600,000 |
WTC7107-650 |
84" x 120" x 84" |
104" x 134" x 135" |
650oF |
10,000 |
7½ |
5" |
100 |
700,000 |
WTC7127-500 |
84" x 144" x 84" |
104" x 157" x 135" |
500oF |
12,500 |
10 |
4" |
100 |
700,000 |
WTC7127-650 |
84" x 144" x 84" |
106" x 158" x 136" |
650oF |
12,500 |
10 |
5" |
140 |
1,200,000 |
WTC8108-500 |
96" x 120" x 96" |
118" x 133" x 147" |
500oF |
12,500 |
10 |
4" |
120 |
800,000 |
WTC8108-650 |
96" x 120" x 96" |
120" x 134" x 148" |
650oF |
12,500 |
10 |
4" |
120 |
800,000 |
WTC8128-500 |
96" x 144" x 96" |
118" x 157" x 158" |
500oF |
17,500 |
15 |
4" |
140 |
1,200,000 |
WTC8128-650 |
96" x 144" x 96" |
120" x 158" x 159" |
650oF |
17,500 |
15 |
5" |
180 |
1,200,000 |
